2000 Series Dual Mode Servo (25-1)
SKU:
DISCONTINUED This product has been discontinued.
$24.99
This servo has been replaced by the 2000 Series Dual Mode Servo (25-2) designed with ultra stout steel gear train.
Downloads
Specs
| Weight | 58g |
|---|---|
| Output Shaft Style | 25 Tooth Spline |
| Voltage Range | 4.8V ~ 6V |
| No-Load Speed (4.8V) | 0.15 sec/60° (66.7 RPM) |
| No-Load Speed (6.0V) | 0.13 sec/60° (76.9 RPM) |
| Stall Torque (4.8V) | 10.1 kg.cm (168 oz-in) |
| Stall Torque (6.0V) | 14.5 kg.cm (201 oz-in) |
| Max PWM Range | 500 - 2500 μsec |
| Travel per µsec (out of box) | 0.14°/μsec |
| Max Travel (out of box) | 280° |
| Pulse Amplitude | 3-5V |
| Direction | Clockwise w/ Increasing PWM Signal |
| Deadband Width | 2 μsec |
| Motor Type | Carbon Brushed DC |
| Feedback Style | 5KΩ Potentiometer |
| Output Shaft Support | Dual Ball Bearing |
| Gear Material | Metal |
| Wire Length | 300 mm |
| Wire Gauge | 22 AWG |
| Connector Type | 3-Pos TJC8 Servo Connector [MH-FC] |
