Hitec HS-488HB Servo

SKU:
$17.59

The HS-488HB servo is based around the popular HS-485HB but with a few noteworthy changes.  To be more compatible with a wider spectrum of the servos and attachments on the market, the HS-488HB has a 25 tooth spline.  This makes bulking up supporting parts much easier as you are able to stick to one spline size rather than bouncing back and forth between 24 and 25.  The new spline comes with a larger servo screw that has a 2.5mm hex drive rather than a Phillips drive.  The HS-488HB also has an updated potentiometer which has allowed the removal of the mechanical stops in the geartrain.  Without mechanical stops you can drive the servo to the extremes in terms of range of motion without concern of contacting a mechanical stop which puts the servo in a stall situation.

Downloads

Specs

Weight 45g
Type Analog
Output Shaft Style 25 Tooth Spline
Voltage Range 4.8V ~ 6V
No-Load Speed (4.8V) 0.22 sec/60°
No-Load Speed (6.0V) 0.18 sec/60°
Stall Torque (4.8V) 4.8 kg.cm (66.6 oz-in)
Stall Torque (6.0V) 6.0 kg.cm (83.3 oz-in)
Max PWM Range 553-2425μsec
Travel per µsec 0.102°/μsec
Pulse Amplitude 3-5V
Direction Clockwise w/ Increasing PWM Signal
Deadband Width 8 μsec
Motor Type 3 Pole Ferrite
Feedback Style 5KΩ Potentiometer
Output Shaft Support Top Ball Bearing, Bottom Bushing
Gear Material Karbonite
Wire Length 300mm
Wire Gauge 25 AWG
Connector Type 3-Pos TJC8 Servo Connector [MH-FC]
