XT30 Power Distribution Board (XT30 Input, 8 x XT30 Outputs)
SKU:
$17.99
The Power Distribution Board delivers power throughout your build. Simply plug your power source into one of its XT30 connectors to power them all! The voltage is distributed across all of the remaining connectors, including side connectors that are conveniently located to daisy-chain with electrical components. And thanks to thru-holes (with nifty hex counterbores) on the goBILDA® 32mm square pattern, it’s super mountable to almost anything in the goBILDA® system!
Downloads
Specs
| Weight | 37g (Includes mounting hardware) |
|---|---|
| Max Total Current | 60A |
| Max Total Current (Continuous) | 30A |
| Hardware Included | 20mm Length M4 Socket Head Screw x 4, M4 x 0.7mm Nylock Nut x 4 |
